Technical Documents
Specifications
Brand
STMicroelectronicsMaximum Continuous Collector Current Ic
30A
Product Type
Trench Gate Field Stop IGBT
Maximum Collector Emitter Voltage Vceo
600V
Maximum Power Dissipation Pd
260W
Package Type
TO-247
Mount Type
Through Hole
Channel Type
Type N
Pin Count
3
Maximum Gate Emitter Voltage VGEO
±20 V
Maximum Collector Emitter Saturation Voltage VceSAT
2V
Minimum Operating Temperature
-55°C
Maximum Operating Temperature
175°C
Length
15.75mm
Height
20.15mm
Standards/Approvals
RoHS
Series
HB
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
P.O.A.
Each (Supplied in a Tube) (ex VAT)
Production pack (Tube)
2
P.O.A.
Each (Supplied in a Tube) (ex VAT)
Stock information temporarily unavailable.
Production pack (Tube)
2
