Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
IGBT
Maximum Continuous Collector Current Ic
10A
Maximum Collector Emitter Voltage Vceo
600V
Maximum Power Dissipation Pd
88W
Package Type
TO-220
Mount Type
Through Hole
Channel Type
Type N
Pin Count
3
Switching Speed
1MHz
Maximum Collector Emitter Saturation Voltage VceSAT
1.95V
Maximum Gate Emitter Voltage VGEO
20 V
Minimum Operating Temperature
-55°C
Maximum Operating Temperature
175°C
Length
10.4mm
Standards/Approvals
No
Series
Trench Gate Field Stop
Height
9.15mm
Automotive Standard
No
Energy Rating
221mJ
Country of Origin
China
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
SR 60.00
SR 6.00 Each (In a Pack of 10) (ex VAT)
SR 69.00
SR 6.90 Each (In a Pack of 10) (inc. VAT)
Standard
10
SR 60.00
SR 6.00 Each (In a Pack of 10) (ex VAT)
SR 69.00
SR 6.90 Each (In a Pack of 10) (inc. VAT)
