Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
IGBT
Maximum Continuous Collector Current Ic
6A
Maximum Collector Emitter Voltage Vceo
1200V
Maximum Power Dissipation Pd
25W
Package Type
TO-220
Mount Type
Through Hole
Channel Type
Type N
Pin Count
3
Switching Speed
1MHz
Maximum Collector Emitter Saturation Voltage VceSAT
2.8V
Minimum Operating Temperature
-55°C
Maximum Gate Emitter Voltage VGEO
20 V
Maximum Operating Temperature
150°C
Length
10.4mm
Height
16.4mm
Standards/Approvals
No
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
SR 70.00
SR 14.00 Each (In a Pack of 5) (ex VAT)
SR 80.50
SR 16.10 Each (In a Pack of 5) (inc. VAT)
Standard
5
SR 70.00
SR 14.00 Each (In a Pack of 5) (ex VAT)
SR 80.50
SR 16.10 Each (In a Pack of 5) (inc. VAT)
Stock information temporarily unavailable.
Standard
5
