Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
MOSFET
Channel Type
Type N
Maximum Continuous Drain Current Id
17A
Maximum Drain Source Voltage Vds
30V
Package Type
TO-252
Series
STripFET
Mount Type
Surface
Pin Count
3
Maximum Drain Source Resistance Rds
60mΩ
Channel Mode
Enhancement
Typical Gate Charge Qg @ Vgs
4.8nC
Maximum Power Dissipation Pd
30W
Minimum Operating Temperature
-55°C
Forward Voltage Vf
1.5V
Maximum Operating Temperature
175°C
Length
6.6mm
Height
2.4mm
Standards/Approvals
No
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
P.O.A.
Each (Supplied on a Reel) (ex VAT)
Production pack (Reel)
10
P.O.A.
Each (Supplied on a Reel) (ex VAT)
Stock information temporarily unavailable.
Production pack (Reel)
10
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
