Technical Documents
Specifications
Brand
STMicroelectronicsDiode Configuration
Single
Product Type
ESD Protection Diode
Direction Type
Bi-Directional
Minimum Breakdown Voltage Vbr
5.8V
Mount Type
Surface
Package Type
0201
Maximum Reverse Stand-off Voltage Vwm
5.3V
Pin Count
2
Peak Pulse Power Dissipation Pppm
20W
Clamping Voltage VC
11.7V
Minimum Operating Temperature
-55°C
Test Current It
1mA
Maximum Peak Pulse Current Ippm
1.7A
ESD Protection
Yes
Number of Elements per Chip
1
Maximum Operating Temperature
150°C
Height
0.32mm
Length
0.63mm
Standards/Approvals
No
Width
0.33mm
Maximum Reverse Leakage Current
100nA
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
SR 22.00
SR 0.22 Each (Supplied as a Tape) (ex VAT)
SR 25.30
SR 0.253 Each (Supplied as a Tape) (inc. VAT)
Standard
100
SR 22.00
SR 0.22 Each (Supplied as a Tape) (ex VAT)
SR 25.30
SR 0.253 Each (Supplied as a Tape) (inc. VAT)
Stock information temporarily unavailable.
Standard
100
