Technical Documents
Specifications
Brand
Renesas ElectronicsProduct Type
Operational Amplifier
Mount Type
Through Hole
Package Type
PDIP
Number of Channels
1
Pin Count
8
GBP - Gain Bandwidth Product
500kHz
Minimum Supply Voltage
3V
Maximum Supply Voltage
36V
Input Bias Current
50 pA
Minimum Operating Temperature
-55°C
Vos - Input Offset Voltage
15 mV
Slew Rate
0.5V/μs
Maximum Operating Temperature
125°C
Height
4.95mm
Length
10.16mm
Standards/Approvals
RoHS
Series
CA3240
Output Current
20mA
Automotive Standard
No
Input Offset Current
32 pA
Product Details
