Technical Documents
Specifications
Brand
OmronProduct Type
Photoelectric Sensor
Sensor Style
Block
Detection Type
Diffuse
Output Type
NPN
Terminal Type
4-Pin Connector
Maximum DC Voltage
24V dc
Interface Type
NPN
Light Source
Infrared
Minimum Operating Temperature
-25°C
IP Rating
IP67
Materials Detected
Paper
Maximum Current
30mA
Maximum Operating Temperature
55°C
Standards/Approvals
CE
Response Time
1ms
Hazardous Area Certification
No
Series
E3Z
Housing Material
Polybutylene Terephthalate
Mount Type
Screw
Thread Size
M8
Detection Range
5 mm → 100 mm
Product Details
