C & K Flush Rotary Coded DIP Switch Surface Mount

Name: C & K Flush Rotary Coded DIP Switch Surface Mount
Brand: C & K
SKU: 7931743P

RS Stock No.: 793-1743PBrand: C & KManufacturers Part No.: SDA03H0SBR

View all in DIP & SIP Switches

Technical Documents

Specifications

Brand

C & K

Product Type

Rotary Coded DIP Switch

Mount Type

Surface Mount

Actuator Type

Flush

Product Details

C & K SDA Series Low Profile

C & K SDA series of DIP switches are SPST switches that are available with through hole or surface mount terminals and raised or flush actuators . Applications include telecom, computers, test equipment, security and instrumentation.

Switch contact rating: 100 mA @ 5 V dc / 25 mA @ 24 V dc
Electrical Life: 1000 cycles minimum
