Technical Documents
Specifications
Brand
Alpha WireProduct Type
Control Cable
Series
Alpha Essentials Communication & Control
Number of Cores
10
Conductor Material
Tin Copper Wire
Jacket Material
Polyvinyl Chloride
Jacket Colour
Grey
Screened/Unscreened
Unscreened
Outside Diameter
8.13mm
Cable Length
30m
Voltage
300V
Minimum Operating Temperature
-20°C
Maximum Operating Temperature
80°C
Standards/Approvals
UL, CSA, CE
Cable CSA
0.56mm²
Hazardous Area Certification
No
American Wire Gauge
20AWG
Fire Behaviour
VW-1, FT4, FT1
Core Strands
7
Product Details
Stock information temporarily unavailable.
SR 1,421.00
SR 1,421.00 1 Reel of 30 Metres (ex VAT)
SR 1,634.15
SR 1,634.15 1 Reel of 30 Metres (inc. VAT)
1
SR 1,421.00
SR 1,421.00 1 Reel of 30 Metres (ex VAT)
SR 1,634.15
SR 1,634.15 1 Reel of 30 Metres (inc. VAT)
Stock information temporarily unavailable.
1
