Schaffner, FN2070 3A 250 V ac/dc DC → 400Hz, Chassis Mount EMI Filter, Fast-On, Single Phase

RS Stock No.: 219-2937Brand: SchaffnerManufacturers Part No.: FN2070-3-06Distrelec Article No.: 16967228
brand-logo
View all in Power Line Filters

Technical Document

Specifications

Maximum Current Rating

3A

Maximum Voltage Rating

250 V ac/dc

Mounting Type

Chassis Mount

Termination Style

Fast-On

Number of Phases

1

Number of Stages

Two Stage

Series

FN2070

Operating Frequency

DC → 400Hz

Length

85mm

Depth

54mm

Height

40.3mm

Capacitance

4.7 nF, 470nF

Dimensions

85 x 54 x 40.3mm

Inductance

9.8 mH

Minimum Operating Temperature

-25°C

Leakage Current

0.734 mA

Maximum Operating Temperature

+100°C

Resistance

470kΩ

Power Loss

2.2W

Country of Origin

Thailand

Product details

FN 2070 Series

Schaffner's FN2070 two-stage filters are designed for easy and fast chassis mounting. All filters provide a high conducted attenuation performance based on chokes with high saturation resistance and excellent thermal behaviour.

Can be used in a wide range of applications such as electrical and electronic equipment, building automation, industrial applications, machinery, medical equipment and various noisy applications requiring good filter performance.

Two-stage chassis mount filters in aluminium case
Component values are selected to give improved performance in both differential and common mode, particularly at high frequencies
Connection by 0.25in Faston terminals
Optional medical versions (B type) & safety versions (A type) available

Approvals

UL recognised, CSA Certified, VDE
