Nichicon 6800μF Aluminium Electrolytic Capacitor 63V dc, Snap-In - LLS1J682MELB

RS Stock No.: 846-7120Brand: NichiconManufacturers Part No.: LLS1J682MELB
brand-logo
View all in Aluminium Capacitors

Technical Document

Specifications

Brand

Nichicon

Capacitance

6800µF

Voltage

63V dc

Mounting Type

Snap-In

Technology

Aluminium Electrolytic

Dimensions

30 (Dia.) x 40mm

Height

40mm

Minimum Operating Temperature

-40°C

Diameter

30mm

Maximum Operating Temperature

+85°C

Lifetime

3000h

Lead Pitch

10mm

Ripple Current

4.55A

Leakage Current

1.96 mA

Tolerance

±20%

Series

LS

Country of Origin

Malaysia

Product details

Nichicon LS Series, General Purpose, Snap-In Aluminium Electrolytic Capacitors

Nichicon LS series are standard 85⁰C snap-in aluminium electrolytic capacitors. They can withstand 3000 h of rated ripple current with voltage ranging from 16 V to 450 V. These high performance and high capacitance parts are ideal for filtering and storing input current.
