Eaton Overload Relay 2NO + 2NC, 6 A Contact Rating, 3 W, 24 Vac, 4P

RS Stock No.: 866-1284Brand: EatonManufacturers Part No.: 276403 DILA-22(24V50/60HZ)
brand-logo
View all in Contactor Overload Relays

Technical Document

Specifications

Brand

Eaton

Contact Current Rating

6 A

Pole Configuration

4P

Mounting Style

DIN Rail Mount

Power Rating

3 W

Normal State Configuration

2NO + 2NC

Reset Method

Manual

Terminal Type

Screw

Number Of Auxiliary Contacts

2

Width

68mm

Depth

75mm

Length

45mm

Minimum Operating Temperature

-25°C

Maximum Operating Temperature

+60°C

Operating Temperature Range

-25 → +60 °C

Coil Voltage

24 V

Contact Voltage Rating

500 V ac

Control Voltage

24 Vac

Product details

Eaton Cutler-Hammer Miniature Overload Relays

The Cutler-Hammer XT miniature overload relays from Eaton feature non reversing and reversing mini contactors, mini overload relays and Snap-On accessories. The XT range of mini overload relays has a compact design which is best suited to be applied in light duty loads such as hoisting, packaging, heating, lighting and automation systems.

Economically and environmentally friendly
Compact design
Phase Failure Sensitivity
Direct Mount to XTMC Mini Contactors
Trip Class 10
9 Settings to Cover 0.24-12 A

Eaton XT Series
