Amprobe 34XRA Handheld Digital Multimeter, True RMS, 10A ac Max, 10A dc Max, 750V ac Max

Brand

Multimeter Type

Handheld

Model Number p

34XRA

Display Type

Digital

Model Number (p)

34XRA

Functions Measured

AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature

Absolute Maximum AC Voltage Measurement

750V ac

Absolute Maximum DC Current Measurement

10A dc

Absolute Maximum Resistance Measurement

40MΩ

Absolute Maximum AC Current Measurement

10A ac

Absolute Maximum DC Voltage Measurement

1000V dc

Absolute Maximum Capacitance Measurement

4mF

Absolute Maximum Temperature Measurement

+1000°C

Maximum Frequency

2kHz

AC Current Measurement Resolution

0.1µA ac

DC Current Measurement Resolution

0.1µA dc

AC Voltage Measurement Resolution

100µV ac

Resistance Measurement Resolution

100mΩ

DC Voltage Measurement Resolution

100µV dc

Safety Category Level

CAT II, CAT III

Capacitance Measurement Resolution

1nF

Temperature Measurement Resolution

1°C

Best AC Current Accuracy

±2.5% + 10 Digits

Width

92mm

Dimensions

196 x 92 x 60mm

Best Temperature Measurement Accuracy

±3% + 2 °C

Best AC Voltage Accuracy

±2% + 8 Digits

Best Capacitance Measurement Accuracy

±5% + 15 Digits

Minimum Operating Temperature

0°C

Height

60mm

Weight

400g

Best DC Current Accuracy

±2% + 3 Digits

Safety Category Voltage

600 V, 1000V

Battery Type

9V

Best Resistance Measurement Accuracy

±2% + 5 Digits

Length

196mm

Best DC Voltage Accuracy

±0.5% + 1 Digit

Maximum Operating Temperature

+50°C

Country of Origin

Taiwan, Province Of China
