Aim-TTi TGF4162 Function Generator, 1μHz Min, 160MHz Max, FM Modulation, Variable Sweep

Brand

Maximum Frequency Range Sinewave

160MHz

Maximum Frequency Range (Sinewave)

160MHz

Number of Channels

2

Maximum Frequency Range Square Pulse and Arbitrary Waveform

100 (Square & Pulse) MHz, 80 (Arbitrary)MHz

Maximum Frequency Range (Square, Pulse and Arbitrary Waveform)

100 (Square & Pulse) MHz, 80 (Arbitrary)MHz

Series

TGF4000

Output Impedance

50Ω

Minimum Frequency Range Sinewave

1µHz

Minimum Frequency Range (Sinewave)

1µHz

Variable Sweep

Yes

Minimum Frequency Range Square Pulse and Arbitrary Waveform

1 μHz

Minimum Frequency Range (Square, Pulse and Arbitrary Waveform)

1 μHz

FM Modulation

Yes

Time Base Accuracy

<±1 (Initial Settling Error) ppm, <±1(Oscillator Aging Rate) ppm, <1(Temperature Range) ppm

Digital Frequency

Yes

Maximum Frequency Range Triangle/Saw

5MHz

Maximum Frequency Range (Triangle/Saw)

5MHz

Minimum Frequency Range Triangle/Saw

1µHz

Minimum Frequency Range (Triangle/Saw)

1µHz

Height

97mm

Interface Type

GPIB, LAN, USB

Minimum Operating Temperature

+5°C

Frequency Range Square Pulse and Arbitrary Waveform

1 μHz → 100 MHz (Square & Pulse), 80 (Arbitrary) MHz

Length

250mm

Model Number

TGF4162

Dimensions

250 x 295 x 97mm

Input Impedance

10 kΩ

Operating Temperature Range

+5 → +40 °C

Internal and External Amplitude Modulation

Yes

Output Amplitude

10V Pk-Pk

Maximum Operating Temperature

+40°C

Internal Linear and Log Sweep

Yes

Frequency Range (Square, Pulse and Arbitrary Waveform)

1 μHz → 100 MHz (Square & Pulse), 80 (Arbitrary) MHz

Weight

3.1kg

Digital Amplitude and Offset

Yes

Width

295mm

TTL Output Level

10V Pk-Pk

Country of Origin

United Kingdom
