Microchip TC4420CPA MOSFET Gate Driver 1, 6 A, 18V 8-Pin, PDIP

RS Stock No.: 681-1124Brand: MicrochipManufacturers Part No.: TC4420CPA
brand-logo
View all in Gate Drivers

Technical Document

Specifications

Brand

Microchip

Logic Type

CMOS, TTL

Output Current

6 A

Supply Voltage

18V

Pin Count

8

Package Type

PDIP

Number of Outputs

2

Driver Type

MOSFET

Topology

Low Side

Number of Drivers

1

Polarity

Non-Inverting

Mounting Type

Through Hole

Height

3.3mm

Maximum Operating Temperature

+70 °C

Dimensions

9.46 x 6.35 x 3.3mm

Length

9.46mm

Product details

TC4420 MOSFET Drivers

MOSFET & IGBT Drivers, Microchip
